Specifications (v1.1.1)
User interface
* Streamlined user interface for fast editing at the sample-zone level.
* Fast editing of multiple zones.
* "In context"-sample preview.
* Extensive drag & drop support (onto the keyrange-view or the list-view).
Sample/Intrument import
* RIFF wave-files (.wav) (8/16/24/32-bit & 32-bit float, mono/stereo at any sample rate)
* AKAI S5000/S6000/Z4/Z8 .akp banks (partial)
* NI battery kits (partial)
* Soundfont 2.00 (partial)
* Propellerhead Recycle 1 & 2
Sampler engine
* High-quality sinc interpolation
* Oversampling used when needed to prevent aliasing
* Double-precision float math (64-bit) used where it matters (IIR-filters).
* Single-precision float math (32-bit) used elsewhere.
* Supports any sample-rate.
* Max polyphony per instance: 256 voices
* Multiple outputs. (max 16 mono AND 8 stereo-pairs per instance)
* Supported sample-playback modes:
playback modes:
forward
forward loop
forward loop with crossfading
forward loop until release
forward loop bidirectional
forward shot
sliced (maps slices accross the keyboard)
on release
reverse
reverse shot
* 2 filters / voice
Filter algorithms:
Lowpass 2-pole (2 types)
Lowpass 1/2/3/4-pole ladder-filter
Lowpass 1/2/3/4-pole ladder-filter with saturation
Highpass 2-pole
Bandpass
Peak
Notch
Dual bandpass
Dual peak
Comb filter
2-band parameric EQ (2 types)
graphic EQ
morphEQ
mörder OD (overdrive)
Bitf*cker
Distortion
Clipper
Gate
Limiter
Slewer
Microgate (does glitch/loop style effects when the gate is open)
Ring modulation
Phase modulation (equivalent to FM)
Frequency shifting
Pulse oscillator
Pulse oscillator (with sync)
Sawtooth oscillator (with 1-16 voices in unison)
Sinus oscillator
* 3 stepLFOs / voice. Doubles as 32-step stepsequencer and wavetable LFO.
* 2 AHDSR envelopes / voice
* Powerful modulation system with the ability to modulate itself. Destinations include envelope-times, loop-points in addition to traditional destinations.
* Group LFO
* Group modulation routing.
* Group effects. (2 effects / group)
Effect types:
digidelay (feedback, filtering & optional midi-sync)
freqshift delay
chorus
freqshift flange
digidist
stereo width
MS decoder
System requirements
* Microsoft Windows 2000, XP or newer.
* Processor with SSE-support (includes Intel Pentium 3 and newer, AMD Athlon XP and newer)
* Software capable of hosting VST-instruments.
