Jack escribió:Salida de audifonos (móvil, etc.) Line In SI (no es la mejor pareja, pero funciona, porque hay manera de controlar la señal en el mixer, y aún así, si la salida del mixer es de Linea, pues hagan las cuentas. Seguimos con una señal de LINEA --10K ohms).
Alguien escribió:Input Impedance
Mic 1.5 kOhm
Line 10 kOhm
Output Impedance
Line 50 Ohms
Headphones to drive >100 Ohm
Maximum Output
Line +21dBu
Headphones +21 dBu
Alguien escribió:Analog audio out using the headphone jack (typical values)
Based on a typical situation with playback of 1 kHz, -3dBFS 24-bit sine wave, 44.1 kHz output sample rate into 150 ohms unless otherwise specified below.
Output voltage: 1.4 volts (root mean square) (Vrms) (+5.1 dBu)
Output impedance: 24 ohms
Output power: 90 milliwatts (mW)
Signal-to-noise ratio: Greater than 90 dB
Total harmonic distortion + noise: Less than -75 dB (.02 percent)
Channel separation: Greater than 50 dB
Jack escribió:
LINE OUT Headphones NO. La impedancias de los audifonos será de unos 600 ohms para abajo (varía). Si acaso se llega a escuchar algo, será distorsionado y tan bajo el nivel (aún con los audífonos más sensibles), aún estando el mixer al máximo, que será inútil.
Alguien escribió:
Impedance 300 Ohm
Sound Pressure Level 107 dB / 1 Vrms
Jack escribió:
HEADPHONE OUT LINE IN -- SI
LINE OUT HEADPHONES -- NO
COMPRENDE?
Alguien escribió:Output
Impedance approx. 80 Ω
Max output level +16 dBu
Alguien escribió:Output
Impedance min. 30 Ω
Max output level approx. +10 dBu (60 mW) @ 100 Ω load
